Danfoss 11109037

PROT.GEAR MOTOR GR2 FAN DRIVE WITH VALVE

MPN: 11109037
Category: Gear motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11109037?

Danfoss PROT.GEAR MOTOR GR2 FAN DRIVE WITH VALVE, manufacturer part number 11109037. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

D_SIZE GROUP2	Group 2:from 3 to 28 cc
Displacement	Displacement 17 cc
Drive gear	Spline DIN 5482 B17 x 14 L=14 SC02
E_VALVE GROUP2	DCV+PVLP+PRV Valve (Reversin
F_DRAIN GROUP2	Inlet on cover - Outlet on cover - drain on cover driven gear position
Inlet size	Without inlet
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Outrig.06 1:8-M12x1,25-Key=
O-Ring, Inside Diameter	Slash
Outlet size	Without inlet
Ports position	Standard from catalogue
Project version	Generation II
Proposition 65	Cancer and Reproductive Harm
Rear cover	Cover M+In-Out 7/8+DCV 12VD
ROTATION	Product with counter-clockwise rotation
Screws	Screws standard
Seals	Standard seal
Slash separator	Slash
Valve setting	Setting proportional valve, type of connector 12 DT Volt and pressure 210 bar with oil ISO VG68 a 40°-50°C
