Danfoss 11106100

GEAR MOTOR GR2 BIDIRECT FIXED DISPL

MPN: 11106100
Category: Gear motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11106100?

Danfoss GEAR MOTOR GR2 BIDIRECT FIXED DISPL, manufacturer part number 11106100. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Displacement	Displacement 8,0 cc
Drive gear	Parallel SAE diam. 15,875 L=23,8 , Key 4x18 CI06
Inlet size	7/8-14UNF
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Flange SAE A, pilot Ø82,55 mm and 2 holes for bolts
O-Ring, Inside Diameter	Slash
Outlet size	7/8-14UNF
Ports position	Standard from catalogue
Project version	Standard with precharge seal on cover
Proposition 65	Cancer and Reproductive Harm
Rear cover	Cover for motor with side drain at 22° left 7/16-20UNF-2B ((LFP-180°)
ROTATION	Bidirectional
Screws	Screws standard
Seals	Standard seal
Single Stage Family	Gr2 Bidir.Motor-Vert.drain
Slash separator	Slash
Valve setting	without setting
