Home / Danfoss (Drives) / Gear motors / Danfoss 11100618

Danfoss 11100618

PROT.GEAR MOTOR GR2 UNIDIRECT FAN DRIVE

MPN: 11100618
Category: Gear motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11100618?

Danfoss PROT.GEAR MOTOR GR2 UNIDIRECT FAN DRIVE, manufacturer part number 11100618. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

D_SIZE GROUP2	Group 2:from 3 to 28 cc
Displacement	Displacement 8,0 cc
Drive gear	Spline DIN 5482 B17 x 14 L=14 SC02
E_VALVE GROUP2	Anti-cavitation check valve on the bearings
F_DRAIN GROUP2	Inlet on cover - Outlet on cover - drain on cover driven gear position
Inlet size	Without inlet
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Outrig.06 1:8-M12x1,25-Key=
O-Ring, Inside Diameter	Slash
Outlet size	Without inlet
Ports position	Standard from catalogue
Project version	Generation II
Proposition 65	Cancer and Reproductive Harm
Rear cover	Cover M+Thd In-Out 7/8-14UN
ROTATION	Product with counter-clockwise rotation
Screws	Screws standard
Seals	Standard seal
Slash separator	Slash
Valve setting	without setting

11100618: frequently asked questions

When can 11100618 be shipped?

11100618 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 11100618 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 11100618 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11100618, subject to availability and destination.
