Danfoss 11089881

GEAR MOTOR GR2 FAN DRIVE

MPN: 11089881
Category: Gear motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11089881?

Danfoss GEAR MOTOR GR2 FAN DRIVE, manufacturer part number 11089881. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

D_SIZE GROUP2	Group 2:from 3 to 28 cc
Displacement	Displacement 11 cc
Drive gear	Taper 1:8 - M12 x 1,25 - Key = 4 CO01
E_VALVE GROUP2	Without Valve
F_DRAIN GROUP2	Inlet on cover - Outlet on cover - drain on cover driven gear position
Inlet size	Without inlet
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Flange SAE A, pilot Ø82,55 mm and 2 holes for bolts
O-Ring, Inside Diameter	Slash
Outlet size	Without inlet
Ports position	Standard from catalogue
Project version	Generation II
Proposition 65	Cancer and Reproductive Harm
Rear cover	Cover M+Thd In-Out 7/8-14 r
ROTATION	Bidirectional
Screws	Screws standard
Seals	Standard seal
Slash separator	Slash
Valve setting	without setting

11089881: frequently asked questions

When can 11089881 be shipped?

11089881 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 11089881 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 11089881 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11089881, subject to availability and destination.
