Danfoss 11075230

GEAR MOTOR GR2 BIDIRECT FIXED DISPL

MPN: 11075230
Category: Gear motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11075230?

Danfoss GEAR MOTOR GR2 BIDIRECT FIXED DISPL, manufacturer part number 11075230. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

D_SIZE GROUP2	2
Displacement	Displacement 17 cc
Drive gear	Spline DIN 5482 B17 x 14 L=14 SC02
E_VALVE GROUP2	Without Valve
F_DRAIN GROUP2	Standard
Inlet size	20x40xM8
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Outrigger Bearing Type 01 with taper shaft 1:8 - M12x1,25 - Key=4 mm
O-Ring, Inside Diameter	Slash
Outlet size	20x40xM8
Ports position	Standard from catalogue
Project version	Standard Version of Project
Proposition 65	Cancer and Reproductive Harm
Rear cover	Standard cover for motor drain 1/4 Gas with holes M5
ROTATION	Bidirectional
Screws	Screws standard
Seals	Standard seal
Single Stage Family	Gr2 Low Cost Bidirec.Motor
Slash separator	Slash
Valve setting	without setting
