Danfoss 11055935

GEAR PUMP GR2 FIXED DISPL

MPN: 11055935
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11055935?

Danfoss GEAR PUMP GR2 FIXED DISPL, manufacturer part number 11055935. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Displacement	Displacement 17 cc
Drive gear	Splined SAE J498-9T-16/32-Dp Class 1FIT - ( rear tang 8 x 17,46 x L=6,5 ) (type 46)
Inlet size	M33x2-ISO6149
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Flange SAE A, pilot Ø82,55 mm and 2 holes for bolts
O-Ring, Inside Diameter	Slash
Outlet size	M22x1,5-ISO6149
Ports position	Standard from catalogue
Project version	Standard Gr2 + Gr1 short version
Proposition 65	Cancer and Reproductive Harm
Rear cover	Not assigned (with intermediate flange instead cover)
ROTATION	Product with counter-clockwise rotation
Screws	Product assembled with 'DACROMET'or 'GEOMET' covering screws (+nuts, washers or cap nuts galvanized if listed on the Bill of Materia)
Seals	Product with VITON shaft seal BA DUO (LBN)
Single Stage Family	Gr2 Main stage
Slash separator	Slash
Valve setting	without setting
