Danfoss 11046413

GEAR PUMP GR2 FIXED DISPL WITH VALVE

MPN: 11046413
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11046413?

Danfoss GEAR PUMP GR2 FIXED DISPL WITH VALVE, manufacturer part number 11046413. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Displacement	Displacement 14 cc
Drive gear	Taper 1:8 - M12 x 1,25 - Key = 4/3,2 CO01 LBD
Inlet size	3/4 GAS
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Flange with pilot Ø36,5 mm and 4 holes for bolts
O-Ring, Inside Diameter	Slash
Outlet size	3/8 GAS
Ports position	Standard from catalogue
Project version	Standard Version of Project
Proposition 65	Cancer and Reproductive Harm
Rear cover	Cover for pump with relief valve with external drain 3/8 Gas
ROTATION	Product with counter-clockwise rotation
Screws	Product with galvanized assembly screws ( +nuts, washers or cap nuts if listed on the Bill of Material )
Seals	Product with VITON seals (LCG)
Single Stage Family	Gr2 Pump+Ext.drain RV
Slash separator	Slash
Valve setting	Setting relief valve, velocity of product per checked setting 2250 rpm and pressure 180 bar with oil ISO VG68 a 40°-50°C

11046413: frequently asked questions

When can 11046413 be shipped?

11046413 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 11046413 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 11046413 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11046413, subject to availability and destination.
