Danfoss 11045280

GEAR PUMP GR2 FIXED DISPL WITH VALVE

MPN: 11045280
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11045280?

Danfoss GEAR PUMP GR2 FIXED DISPL WITH VALVE, manufacturer part number 11045280. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Displacement	Displacement 4,0 cc
Drive gear	Splined SAE J498-9T-16/32-Dp Class 1FIT -SC06
Inlet size	1/2 GAS
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Flange SAE A, pilot Ø82,55 mm and 2 holes for bolts
O-Ring, Inside Diameter	Slash
Outlet size	1/2 GAS
Ports position	Standard from catalogue
Project version	Standard Version of Project
Proposition 65	Cancer and Reproductive Harm
Rear cover	Cover for pump with relief valve with external drain 3/8 Gas
ROTATION	Product with clockwise rotation
Screws	Screws standard
Seals	Standard seal
Single Stage Family	Gr2 Pump+Ext.drain RV
Slash separator	Slash
Valve setting	Setting relief valve, velocity of product per checked setting 2250 rpm and pressure 100 bar with oil ISO VG68 a 40°-50°C
