Danfoss 11038825

GEAR PUMP GR2 FIXED DISPL

MPN: 11038825
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11038825?

Danfoss GEAR PUMP GR2 FIXED DISPL, manufacturer part number 11038825. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Displacement	Displacement 17 cc
Drive gear	Splined SAE J498-11T-16/32-Dp Class 1FIT - ( rear tang 8 x 19,94 x L=6,5 ) (type 36)
Inlet size	1-1/16-12UN
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	VOLVO Marking
Mounting flange	Flange SAE A, pilot Ø82,55 mm and 2 holes for bolts
O-Ring, Inside Diameter	Slash
Outlet size	7/8-14UNF
Ports position	Standard from catalogue
Project version	Standard Version of Project
Proposition 65	Cancer and Reproductive Harm
Rear cover	Not assigned (with intermediate flange instead cover)
ROTATION	Product with counter-clockwise rotation
Screws	Screws standard
Seals	Standard seal
Single Stage Family	Gr2 Hi.Torque-Main stage
Slash separator	Slash
Valve setting	without setting
