Danfoss 11038429

TANDEM=GEAR PUMP GR3+GEAR PUMP GR1

MPN: 11038429
Category: GearMe modular two stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11038429?

Danfoss TANDEM=GEAR PUMP GR3+GEAR PUMP GR1, manufacturer part number 11038429. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A: Tandem Gr.3+1 family	SNW3NN + SNP1NN
B: 1st stage displacement	Displacement 75cc
C: 2nd stage displacement	Displacement 4,3cc
D: Rotation	Product with clockwise rotation
E: Project version	With intermediate flange
F: Mounting flange	Flange with pilot D.50.8 and 4 holes for bolts (98,4x128,1)
G: Drive gear	Taper 1:8 - M14 x 1,5 - Key = 4 ; rear spline DIN 5482 22 x 19 L=16,5 CO41-CO42
H: Rear cover	Standard Cover for pump
I: 1st stage inlet size	36x62xM10
J: 1st stage outlet size	27x51xM10
K: 1st stage ports position	Standard from catalogue
L: 2nd stage inlet size	12x26xM5
M: 2nd stage outlet size	12x26xM5
N: 2nd stage ports position	Standard from catalogue
O-Ring, Inside Diameter	Slash
O: Seals	Standard seal
OC DELIMITER (-)	-
P: Screws	Standard screws
Proposition 65	Cancer and Reproductive Harm
Q: Valve setting	without valve
R: Mark type	Std Sauer Danfoss Marking
S: Mark position	Position Marking standard
Slash separator	Slash
