Danfoss 11034338

TANDEM=GEAR PUMP GR2+GEAR PUMP GR1

MPN: 11034338
Category: GearMe modular two stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11034338?

Danfoss TANDEM=GEAR PUMP GR2+GEAR PUMP GR1, manufacturer part number 11034338. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A: Tandem Gr.2+1 family	SNW2NN + SNP1NN
B: 1st stage displacement	Displacement 14 cc
C: 2nd stage displacement	Displacement 3,8 cc
D: Rotation	Product with clockwise rotation
E: Project version	Standard ( without intermediate flange )
F: Mounting flange	Flange with pilot D.36,5 and 4 holes for bolts
G: Drive gear	Taper 1:8 - M12 x 1,25 - Key = 4 , (Rear shaft tang)
H: Rear cover	Std Cover for pump
I: 1st stage inlet size	20x40xM8
J: 1st stage outlet size	13,5x30xM6
K: 1st stage ports position	Standard from catalogue
L: 2nd stage inlet size	12x26xM5
M: 2nd stage outlet size	12x26xM5
N: 2nd stage ports position	Standard from catalogue
O-Ring, Inside Diameter	Slash
O: Seals	Standard from catalogue
OC DELIMITER (-)	-
P: Screws	Standard from catalogue
Proposition 65	Cancer and Reproductive Harm
Q: Valve setting	without valve
R: Mark type	Std Sauer Danfoss Marking
S: Mark position	Std Position Marking
Slash separator	Slash

11034338: frequently asked questions

When can 11034338 be shipped?

11034338 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 11034338 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 11034338 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11034338, subject to availability and destination.
