Danfoss 11033554

GEAR PUMP GR2 FIXED DISPL

MPN: 11033554
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11033554?

Danfoss GEAR PUMP GR2 FIXED DISPL, manufacturer part number 11033554. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Displacement	Displacement 11 cc
Drive gear	Tang 8 x 17,8 x L=6,5 ( rear tang 8 x 17,46 x L=6,5 ) (type 43)
Inlet size	3/4 GAS
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Flange with pilot Ø52 mm with O-ring and 4 holes for bolts through thebody
O-Ring, Inside Diameter	Slash
Outlet size	1/2 GAS
Ports position	Standard from catalogue
Project version	Standard Gr2 + Gr1
Proposition 65	Cancer and Reproductive Harm
Rear cover	Not assigned (with intermediate flange instead cover)
ROTATION	Product with clockwise rotation
Screws	Screws standard
Seals	Standard seal
Single Stage Family	Gr2 Middle Stage
Slash separator	Slash
Valve setting	without setting
