Danfoss 11030651

GEAR MOTOR GR2 UNIDIRECT FIXED DISPL

MPN: 11030651
Category: Gear motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11030651?

Danfoss GEAR MOTOR GR2 UNIDIRECT FIXED DISPL, manufacturer part number 11030651. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

D_SIZE GROUP2	Group 2:from 3 to 28 cc
Displacement	Displacement 17 cc
Drive gear	Parallel SAE diam. 15,875 L=50,8 , Key 4x40 (CE06)
E_VALVE GROUP2	Without Valve
F_DRAIN GROUP2	Standard
Inlet size	7/8-14UNF
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Special I-RAND Marking (DQST016)
Mounting flange	Flange SAE A, pilot Ø82,55 mm and 2 holes for bolts
O-Ring, Inside Diameter	Slash
Outlet size	1-1/16-12UN
Ports position	Standard from catalogue
Project version	Standard Version of Project
Proposition 65	Cancer and Reproductive Harm
Rear cover	Standard cover for pump
ROTATION	Product with counter-clockwise rotation
Screws	Screws standard
Seals	Standard seal
Slash separator	Slash
Valve setting	without setting
