Home / Danfoss (Drives) / Compensated directional control valves / Danfoss 11020966

Danfoss 11020966

PVP32-INLET-SAE-CC-PPRV-LSRV

MPN: 11020966
Category: Compensated directional control valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11020966?

Danfoss PVP32-INLET-SAE-CC-PPRV-LSRV, manufacturer part number 11020966. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A Side Interface	N/A
Additional Feature	N/A
B Side Interface	N/A
Bottom Interface	Mounting Feet A/B
Certification	N/A
CF Out Nominel Flow	N/A
CF Port Placement	N/A
CF Port Size	N/A
Continous System Pressure	350
Customer Specific Attributes	N/A
Dynamic Response (Damping)	Fixed Orifice LS
Ex Application	Ex h I/II
Extra LS Port Placement	N/A
Extra LS Port Size	N/A
Extra Pump Port Placement	N/A
Extra Pump Port Size	N/A
Extra Tank Port Placement	N/A
Extra Tank Port Size	N/A
Full flow dump Facility	N/A
Gauge Port Pilot Pres Location	N/A
Gauge Port Pilot Pressure Size	N/A
Gauge Port Pump Pressure Size	#5 - 1/2-20 UNF
Gauge Port Tank Pressure Size	N/A
HPCO Port Placement	N/A
HPCO Port Size	N/A
Inlet Compensator/Unloader	10-16 bar @ 10-150 lpm
Left Interface	N/A
LS Boost Facility	N/A
LS Dump Facility	N/A
LS Port Placement	B
LS Port Size	#5 - 1/2-20 UNF
LS Relief	N/A
LX Port Placement	N/A
LX Port Size	N/A
Marking	N/A
Maximum System Pressure Peaks	400
Module Type	Start Module
Mounting Thread Size	5/16-18 UNC
Nominel Flow	150
Pilot Dump Facility	N/A
Pilot Pressure	13.5 (PVE)
Pilot Pressure Accumulator Por	N/A
Port Connection Type	SAE [ISO 11926-1]
Pressure Relief Valve	Both
Primer	Passivation - Transparent
Product Category	Standard Part
Product type	N/A
Proposition 65	Cancer and Reproductive Harm
Pump Configuration	Closed Center/Variable
Pump Port Placement	Top
Pump Port Pressure Location	A
Pump Port Size	#12 - 1 1/16-12 UN
PVPC Facility	Yes
Right Interface	PVG32-Flat
Shock Valve Facility	N/A
T0 Facility	N/A
T0 Port Placement	N/A
T0 Port Size	N/A
Tank Port Placement	Top
Tank Port Pressure Location	N/A
Tank Port Size	#12 - 1 1/16-12 UN
Tie Rod Length	48
Tie Rod Type Left	Through Hole
Tie Rod Type Right	Through Hole
Top Interface	Threaded Ports
Valve Family	PVG16-48
Width	48
