CN29TD(155/89-01-73)
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Track and swing drive piston motors |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 11010214401 be shipped?
11010214401 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 11010214401 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 11010214401 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11010214401, subject to availability and destination.
Danfoss CN29TD(155/89-01-73), manufacturer part number 11010214401. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| A B main port size | SAE 1" 8-M12 |
| Anti cavitation | None |
| Application | Excavator |
| Danfoss track type | Danfoss Track Device (motor+gear box) |
| Design code | First version |
| Device mounting | Standard |
| Displacement (1st 2nd) | 154.8 88.5 cm3/r (9.45 5.4 in3/r) |
| Flow rate GPM | 72.65 |
| Flow rate lpm | 275.0 |
| Gear ratio | 72.9 three stage |
| Gearbox mounting | Standard |
| Identification | Standard nameplate (Danfoss) |
| Maximum output speed RPM | 3006 |
| Motor mounting | Standard |
| Motor shaft | Standard |
| Old model code | JMV155RR060602027300A00A |
| Output torque LBF-IN | 546205.0 |
| Output torque Nm | 61713.2 |
| Paint | Standard: black |
| Parking brake setting | 8.8 bar (128 psi) |
| Product height in | 19.200 |
| Product height mm | 487.680 |
| Product length in | 22.500 |
| Product length mm | 571.500 |
| Product width in | 19.200 |
| Product width mm | 487.68 |
| Relief valve setting | 343bar (4978psi) 40lpm (10.6gp |
| Special requirement | None |
| Two speed setting | 265bar (3840psi) pilot 39bar (569psi) |
| Working pressure bar | 343.0 |
| Working pressure psi | 4975 |
