Danfoss 07.421-4-4

HOSE NIPPLE ASSY, SR/04, BF/04, CS, STR

MPN: 07.421-4-4
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 07.421-4-4?

Danfoss HOSE NIPPLE ASSY, SR/04, BF/04, CS, STR, manufacturer part number 07.421-4-4. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	2.047
A dimension MM	52.000
Angle shape	Straight
Compatible hose ID IN	0.250
Compatible hose ID MM	6.400
Construction Style	Reusable
End size 1	-4
End type 1	Female BSPP swivel
Finish plating	Zinc plating
Hex size 2 MM	17.000
Hose cut off factor IN	1.300
Hose cut off factor MM	33.000
Hose size	-4
Inside diameter IN	0.125
Inside diameter MM	3.200
Product height in	0.710
Product height mm	18.034
Product length in	2.050
Product length mm	52.070
Product material	Carbon steel
Product width in	0.620
Product width mm	15.748 mm
Reusable socket hex IN	0.629
Reusable socket hex MM	16.000
Series	Socketless
Thread size 1	G 1/4
Working pressure max BAR	450
Working pressure max PSI	6550
Working temperature max C	250
Working temperature max F	482
Working temperature min C	-65
Working temperature min F	-85
