Danfoss 04Z-644

Hose End (perm) 1S/1R 90 D F SAE 37 Sw

MPN: 04Z-644
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 04Z-644?

Danfoss Hose End (perm) 1S/1R 90 D F SAE 37 Sw, manufacturer part number 04Z-644. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	639789292551
Angle shape	90 Degree
Brand	Weatherhead by Danfoss
Compatible hose ID IN	0.250
Compatible hose ID MM	6.350
Compatible tube OD IN	0.25
Compatible tube OD MM	6.350
Compliances	SAE J1176
Construction Style	Crimp
Drop dimension IN	1.800
Drop dimension MM	45.70
End size 1	-4
End type 1	Female 37 degree swivel
Finish plating	Dura-Kote
Hex size 1 IN	0.560
Hex size 1 MM	14.200
Hose cut off factor IN	0.920
Hose cut off factor MM	23.368
Hose size	-4
Inside diameter IN	0.1700
Inside diameter MM	4.3180
Product material	Carbon steel
Thread sealant	No
Tube OD 1 IN	0.250
Tube OD 1 MM	6.350
