Danfoss 02-393456

UPF1S 06 F W P 20, UPF1S06FWP20

MPN
02-393456
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 02-393456?

Danfoss UPF1S 06 F W P 20, UPF1S06FWP20, manufacturer part number 02-393456. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

Actuation TypePilot operated
Adjustment range9-245 bar (130-3600 psi)
Adjustment typeScrew with locknut
BrandVickers by Danfoss
Design Series20 Series
Electrical connectionNone
Flow rate lpm100.0
Flow rate USGPM26.0
Fluid Cleanliness19/17/14 Micron
Fluid compatibilityPetroleum oils
Hi-vent springNo
Indicator LightNo
Maximum pressure BAR275
Maximum pressure PSI4000
Model Code 1UPF1S06FWP20
PerformanceStandard
Product height in5.900
Product height mm149.860
Product length in5.530
Product length mm140.462
Product width in2.500
Product width mm63.5
Seal materialNitrile
SizeSAE 3/4"
Special featureNone
StageTwo stage
Tank pressure bar210
Tank pressure PSI3000
Valve Mount TypePump flange mounting
Valve typeUnloading relief valve
Working temperature max C70
Working temperature max F158
Working temperature min C-20
Working temperature min F-4

02-393456: frequently asked questions

When can 02-393456 be shipped?

02-393456 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 02-393456 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 02-393456 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 02-393456, subject to availability and destination.
