What is the Danfoss 02-363101?

Danfoss UPF1S CL 12 B W 20, UPF1SCL12BW20, manufacturer part number 02-363101. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

Actuation TypePilot operated
Adjustment range9-125 bar (130-1800 psi)
Adjustment typeScrew with locknut
BrandVickers by Danfoss
Check valveYes
Cracking pressure bar0.3
Cracking pressure PSI5
Design Series20 Series
Electrical connectionNone
Flow rate lpm600.0
Flow rate USGPM80.0
Fluid Cleanliness19/17/14 Micron
Fluid compatibilityPetroleum oils
Hi-vent springNo
Indicator LightNo
Maximum pressure BAR275
Maximum pressure PSI4000
Model Code 1UPF1SCL12BW20
PerformanceStandard
Product height in6.770
Product height mm171.958
Product length in7.490
Product length mm190.246
Product width in6.130
Product width mm155.702
Seal materialNitrile
SizeSAE 1 1/2"
Special featureNone
StageTwo stage
Tank pressure bar210
Tank pressure PSI3000
Valve Mount TypePump flange mounting
Valve typeUnloading relief valve
Working temperature max C70
Working temperature max F158
Working temperature min C-20
Working temperature min F-4
