Danfoss 02-353239

DGMX1 3 PP BH S 40, DGMX13PPBHS40

MPN
02-353239
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 02-353239?

Danfoss DGMX1 3 PP BH S 40, DGMX13PPBHS40, manufacturer part number 02-353239. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

Actuation TypePressure operated
Adjustment locationAdjuster - B port end of valve
Adjustment typeHandknob
BrandVickers by Danfoss
Design Series40 Series
Flow rate upto LPM60
Flow rate upto USGPM16.0
Fluid Cleanliness19/17/14 micron
Fluid compatibilityPetroleum oils
Function portsReducing line P, pilot line P
Gauge Port Thread TypeSAE 4 (7/16"-20 UNF-2B)
InterfaceISO4401-03
Maximum pressure upto bar315
Maximum pressure upto psi4500
Model Code 1DGMX13PPBHS40
PerformanceStandard
Pressure adjustment range3.5-70 bar (51-1000 psi)
Product height in2.360
Product height mm59.944
Product length in7.050
Product length mm179.070
Product width in2.820
Product width mm71.628
Seal typeViton
Special featuresNone
Valve Mount TypeSubplate/manifold mounted
Valve typeReducing-relieving underlapped
Working temp max C80
Working temp max F176
Working temp min C-20
Working temp min F-4

02-353239: frequently asked questions

When can 02-353239 be shipped?

02-353239 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 02-353239 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 02-353239 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 02-353239, subject to availability and destination.
