Danfoss 02-352620

DGMX 7 PP B H 20, DGMX7PPBH20

MPN
02-352620
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 02-352620?

Danfoss DGMX 7 PP B H 20, DGMX7PPBH20, manufacturer part number 02-352620. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

Actuation TypePressure operated
Adjustment typeHandwheel with locknut
BrandVickers by Danfoss
Design Series20 Series
Flow rate upto LPM250
Flow rate upto USGPM66.0
Fluid Cleanliness19/17/14 micron
Fluid compatibilityAnti-wear hydraulic oil
Function portsReducing line P, pilot line P
InterfaceISO4401-07
Maximum pressure upto bar350
Maximum pressure upto psi5000
Model Code 1DGMX7PPBH20
PerformanceStandard
Pressure adjustment range10-100 bar (145-1454 psi)
Product height in3.150
Product height mm80.010
Product length in9.130
Product length mm231.902
Product width in3.660
Product width mm92.964
Seal typeBuna-N
Special featuresNone
Valve Mount TypeSubplate/manifold mounted
Valve typeReducing-relieving valve
Working temp max C80
Working temp max F176
Working temp min C-25
Working temp min F-13

02-352620: frequently asked questions

When can 02-352620 be shipped?

02-352620 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 02-352620 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 02-352620 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 02-352620, subject to availability and destination.
