Danfoss 02-342573

XCG 06 3B 30, XCG063B30

MPN: 02-342573
Category: Industrial valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 02-342573?

Danfoss XCG 06 3B 30, XCG063B30, manufacturer part number 02-342573. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Actuation Type	Pilot operated
Adjustment range bar	210
Adjustment range PSI	3000
Adjustment type	Screw with locknut
Brand	Vickers by Danfoss
Check valve	Yes
Design Series	30 Series
Electrical connection	None
Flow rate lpm	57.0
Flow rate USGPM	15.0
Fluid Cleanliness	19/17/14 Micron
Fluid compatibility	Petroleum oils
Gauge port thread	1/4 NPTF
Hi-vent spring	No
Indicator Light	No
Maximum pressure BAR	210
Maximum pressure PSI	3000
Model Code 1	XCG063B30
Performance	Standard
Product height in	6.950
Product height mm	176.530
Product length in	6.380
Product length mm	162.052
Product width in	3.600
Product width mm	91.44
Seal material	Nitrile
Size	Size 06
Special feature	None
Stage	Two stage
Valve Mount Type	Subplate/manifold mounted
Valve type	Pressure reducing valve
Working temperature max C	70
Working temperature max F	158
Working temperature min C	-20
Working temperature min F	-4

02-342573: frequently asked questions

When can 02-342573 be shipped?

02-342573 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 02-342573 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 02-342573 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 02-342573, subject to availability and destination.
