Danfoss 02-318400

CVCS-63-ZD3-B2-10, CVCS63ZD3B210

MPN: 02-318400
Category: Industrial valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 02-318400?

Danfoss CVCS-63-ZD3-B2-10, CVCS63ZD3B210, manufacturer part number 02-318400. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Adjustment	No
Brand	Vickers by Danfoss
Cover type	Dynamic with pilot control
Design Series	10 Design
Flow rate LPM	3650
Flow rate USGPM	965.0
Fluid Cleanliness	18/16/13 micron
Fluid compatibility	Water Glycol, Water-in-Oil Emulsions and Petroleum Oil
Gauge port thread	BSPF
Insert ratio	1:1.05
Insert type	Dynamic, Zero Pilot Leakage
Interface	Yes
Leakage	Zero leakage
Model Code 1	CVCS63ZD3B210
Normal function	Normally open
Pilot port orientation	ISO
Pressure rating BAR	350
Pressure rating PSI	5000
Product height in	10.130
Product height mm	257.302
Product length in	7.200
Product length mm	182.880
Product width in	7.200
Product width mm	182.88
Seal material	Buna-N
Size	NG 63
Special feature	None
Spool position sensor	No
Valve type	Cartridge valve cover
Valvistor	No
Working temp max C	70
Working temp max F	158
Working temp min C	-20
Working temp min F	-4
