Danfoss 02-199422

EFV110NCAS00000000000000, EFV1-10-N-C-A-S-0-00

MPN: 02-199422
Category: Cartridge valves

Price and lead time confirmed within 1 business day

Request a Quote

1We check stock, condition and lead time
2You get a written quote by email
3Approve it and we ship — in-stock parts within 1 business day

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
100% positive eBay feedback
Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 02-199422?

Danfoss EFV110NCAS00000000000000, EFV1-10-N-C-A-S-0-00, manufacturer part number 02-199422. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Brand	Vickers by Danfoss
Cavity	C-12-3
Coil series	None
Coil termination	None
Diode	No
Flow rate GPM	4.00
Flow rate LPM	15.000
Fluid compatibility	MIL-H-5606, SAE10, SAE20, etc
Function	Prop Flow Control
Housing	No
Installation type	Screw-in Cartridge
Leakage	197 cc /min
Minimum working pressure BAR	20.00
Minimum working pressure PSI	291.00
Model Code 1	EFV1-10-N-C-A-S-0-00
Number of housing ports	3
Number of valve ports	3
Operating temperature	-30 C to 90 C (-22 to 194 F)
Operation	Elecro Proportionally Ctrl
Override type	Screw-in type
Port size	None
Port type	Cartridge only
Pressure rating BAR	210.00
Pressure rating PSI	3053.00
Product height in	2.130
Product height mm	54.102
Product length in	5.260
Product length mm	133.604
Product width in	1.740
Product width mm	44.196 mm
Recommended filtration level	18/16/13
Seal type	Buna-N
Special features	None
Style	Spool
Torque into aluminium cavity	81-95 Nm
Torque into steel cavity	102-115 Nm
Voltage type	DC
Working pressure max BAR	210.00
Working pressure max PSI	3000.00

02-199422: frequently asked questions

When can 02-199422 be shipped?

02-199422 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 02-199422 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 02-199422 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 02-199422, subject to availability and destination.
