Danfoss 02-198177

DPS2-10-V-F-8H-80 DIFF PRESS SENSING VLV, DPS2-10-V-F-8H-080

MPN: 02-198177
Category: Cartridge valves

Price and lead time confirmed within 1 business day

Request a Quote

1We check stock, condition and lead time
2You get a written quote by email
3Approve it and we ship — in-stock parts within 1 business day

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
100% positive eBay feedback
Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 02-198177?

Danfoss DPS2-10-V-F-8H-80 DIFF PRESS SENSING VLV, DPS2-10-V-F-8H-080, manufacturer part number 02-198177. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Brand	Vickers by Danfoss
Cavity	C-10-3S
Flow rate GPM	16.000
Flow rate LPM	60.00
Fluid compatibility	MIL-H-5606, SAE10, SAE20, etc
Function	Differential Pressure Sensing
Housing	Yes
Installation type	Screw-in Cartridge
Leakage	246 cc/min
Model Code 1	DPS2-10-V-F-8H-080
Normal function	Spool, Normally closed
Number housing ports	3
Number of valve port	3
Operating temp	-40 C to 120 C (-40 to 248 F)
Pilot ratio	1:1
Port type	SAE
Pressure differential BAR	5.50
Pressure differential PSI	80.00
Pressure rating BAR	290.00
Pressure rating PSI	4200.00
Product height in	3.810
Product height mm	96.774
Product length in	3.000
Product length mm	76.200
Product width in	2.000
Product width mm	50.800 mm
Rec filtration level	18/16/13
Seal type	Buna-N
Special features	None
Spring	80 psi
Stroke adjustment	Fixed stroke
Style	Spool

02-198177: frequently asked questions

When can 02-198177 be shipped?

02-198177 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 02-198177 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 02-198177 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 02-198177, subject to availability and destination.
