Danfoss 02-169253

ERV1-10V-15.00-0-00, ERV1-10-V-15-0-00

MPN: 02-169253
Category: Cartridge valves

Price and lead time confirmed within 1 business day

Request a Quote

1We check stock, condition and lead time
2You get a written quote by email
3Approve it and we ship — in-stock parts within 1 business day

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 02-169253?

Danfoss ERV1-10V-15.00-0-00, ERV1-10-V-15-0-00, manufacturer part number 02-169253. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Brand	Vickers by Danfoss
Cavity	C-10-2
Coil series	None
Coil termination	None
Diode	No
Factory set pressure BAR	103.350
Factory set pressure PSI	1500.00
Flow rate GPM	16.00
Flow rate LPM	60.000
Fluid compatibility	MIL-H-5606, SAE10, SAE20, etc
Function	Proportional Pressure Relief
Housing	No
Installation type	Screw-in Cartridge
Minimum working pressure BAR	2.00
Minimum working pressure PSI	29.00
Model Code 1	ERV1-10-V-15-0-00
Number of housing ports	2
Number of valve ports	2
Operating temperature	-40 C to 120 C (-40 to 248 F)
Operation	Elecronically Proportionally Controlled
Override type	None
Port size	None
Port type	Cartridge only
Pressure rating BAR	240.00
Pressure rating PSI	3500.00
Product height in	1.530
Product height mm	38.862
Product length in	4.180
Product length mm	106.172
Product width in	1.530
Product width mm	38.862 mm
Recommended filtration level	18/16/13
Seal type	Viton
Special features	None
Style	Spool
Torque into aluminium cavity	47-54 Nm
Torque into steel cavity	68-75 Nm
Voltage type	DC
Working pressure max BAR	240.00
Working pressure max PSI	3500.00
