Danfoss 02-167426

SV2-10-4-6T-12DG 4/2 SOL/OP VLV 12VDC 6T, SV2-10-4-A-6T-12D-G

MPN: 02-167426
Category: Cartridge valves

Price and lead time confirmed within 1 business day

Request a Quote

1We check stock, condition and lead time
2You get a written quote by email
3Approve it and we ship — in-stock parts within 1 business day

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 02-167426?

Danfoss SV2-10-4-6T-12DG 4/2 SOL/OP VLV 12VDC 6T, SV2-10-4-A-6T-12D-G, manufacturer part number 02-167426. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Brand	Vickers by Danfoss
Cavity	C-10-4
Coil termination	DIN 43650
Diode	No
Flow rate GPM	6.00
Flow rate LPM	23.000
Fluid compatibility	MIL-H-5606, SAE10, SAE20, etc
Function	Solenoid Valve
Housing	Yes
Housing material	Aluminum
Installation type	Screw-in Cartridge
Leakage	164 cm3 /min (10 in3 /min) max @ 210 bar
Model Code 1	SV2-10-4-A-6T-12D-G
Number of housing ports	4
Number of valve ports	4
Operating temperature	-40 C to 120 C (-40 to 248 F)
Operation	Electrically operated
Override type	None
Port size	3/8"
Port type	SAE
Pressure rating BAR	210.00
Pressure rating PSI	3000.00
Product height in	5.750
Product height mm	146.050
Product length in	3.000
Product length mm	76.200
Product width in	2.000
Product width mm	50.800 mm
Recommended filtration level	18/16/13
Seal type	Buna-N
Special features	None
Style	2-Way, 2-Position, Poppet, NC
Voltage	12 V
Voltage type	DC
