What is the Danfoss 02-125654-AAR?

Danfoss 45VQTCS60AS 2297AA 21R, 45VQTCS60AS 2297AA 21R, manufacturer part number 02-125654-AAR. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

PUMP TYPE	VANE TYPE PUMP VQ-MOBILE
Series	INTRAVANE PUMP SERIES
ROT FROM SHAFT END	RIGHT HAND OR CLOCKWISE
THRU DRIVE	THRU DRIVE
ADPMTG ORT ADP END	A ADAPTER- ROTATED 45⁰ CW WITH RESPECT TO PUMP MTG. FLG. B OR C ADAPTER- IN LINE WITH PUMP MTG. FLANGE
BODY MOUNTING FLG	SAE J744 MOUNTING FLANGE
Brand	Vickers by Danfoss
CPLG FOR TAND PUMP	SAE SPLINED COUPLING INCLUDED WITH PUMP
DESIGN NO MOD	DESIGN CODE-DOUBLE SHAFT SEAL
DRIVE SHAFT TYPE	297 - SPLINED, 14 TEETH 12/24 SIDE FIT
IPM FRAME SIZE	45VQ Single Pump
Model Code 1	45VQTCS60AS 2297AA 21R
O POS FROM ADP END	OPPOSITE INLET PORT
PORT MTG SS ASSM	FLANGE MOUNT AND DOUBLE SHAFT SEAL ASSEMBLY
ROTATING GROUP CAP	60 GPM
SAE PORT CONNECTION	INLET-4 BOLT FLG. OUTLET-4 BOLT FLG.
THRU CXN MTG ADP	TWO BOLT SAE 'C' FLANGE
