Danfoss 02-125519-1

35VTBS25A 2297AA22R, 35VTBS25A 2297AA22R

MPN
02-125519-1
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 02-125519-1?

Danfoss 35VTBS25A 2297AA22R, 35VTBS25A 2297AA22R, manufacturer part number 02-125519-1. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

DESIGN NODESIGN NO
IPM FRAME SIZE35VT Thru-Drive Pump
PORT CONNECTIONINLET: 4 BOLT FLANGE OUTLET: 4 BOLT FLANGE
PUMP TYPEVANE PUMP, THRU DRIVE
RING CAPACITY25 GPM
ROTATION FROM SHAFT ENDCLOCKWISE
SeriesSERIES DESIGNATION
SHAFT297- SAE SPLINED 14 TEETH
BODY MOUNTING FLANGESAE J-744 101-2 MOUNTING FLANGE
ADAPTER MTG ORIENTATIONFOR ADAPTER 'A' : ROTATE 45° CW WITH RESPECT TO MOUNTING FLANGE VIEWED FROM ADAPTER END. FOR ADAPTER 'B', 'C': INLINE WITHMOUNTING FLANGE.
COUPLINGWITH SPLINE FOR TANDEM PUMP
OUTLET POSITIONOUTLET OPPOSITE INLET
THRU CONNECTION MTGTWO BOLT SAE 'B' FLANGE
BrandVickers by Danfoss
Model Code 135VTBS25A 2297AA22R

02-125519-1: frequently asked questions

When can 02-125519-1 be shipped?

02-125519-1 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 02-125519-1 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 02-125519-1 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 02-125519-1, subject to availability and destination.
