Danfoss 02-112703

DSV4-10-0-0-40, DSV4-10-0-0-40

MPN: 02-112703
Category: Cartridge valves

Price and lead time confirmed within 1 business day

Request a Quote

1We check stock, condition and lead time
2You get a written quote by email
3Approve it and we ship — in-stock parts within 1 business day

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
100% positive eBay feedback
Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 02-112703?

Danfoss DSV4-10-0-0-40, DSV4-10-0-0-40, manufacturer part number 02-112703. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Actuation option	None
Adjustment type	None
Brand	Vickers by Danfoss
Cavity	C-10-4
Detent option	No
Flow rate GPM	6.90
Flow rate LPM	26.000
Fluid compatibility	MIL-H-5606, SAE10, SAE20, etc
Function	Shuttle Valve
Housing	No
Housing material	None
Installation type	Screw-in Cartridge
Leakage	164 cc/min
Model Code 1	DSV4-10-0-0-40
Number of housing ports	4
Number of valve ports	4
Operating temperature	-40 C to 120 C (-40 to 248 F)
Operation	Dynamic Signal, Pilot operated
Pilot pressure setting BAR	2.75
Pilot pressure setting PSI	40.00
Port type	Cartridge Only
Pressure rating BAR	350.00
Pressure rating PSI	5000.00
Product height in	1.000
Product height mm	25.400
Product length in	3.040
Product length mm	77.216
Product width in	1.000
Product width mm	25.400 mm
Recommended filtration level	18/16/13
Seal type	Buna-N
Special features	Open
Style	3-Way 3-Position
