What is the Danfoss 02-102111?

Danfoss PVH074R13AA10B252000001AF1AB010A, manufacturer part number 02-102111. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

Aux mount output shaft2 BOLT A (SAE J744-82-2) W/ 17T 16/32DP SPLINED SHAFT (ANS B92.1A-1976)
CODE TITLEVICKERS PRESSURE COMPENSATED/PRESSURE FLOW COMPENSATED OPEN CIRCUIT PISTON PUMP
Control special featuresNO CONTROL SPECIAL FEATURES
Controller typePRESSURE AND FLOW COMPENSATOR
Customer identificationNONE - MARK ASSEMBLY NUMBER, COMPLETE MODEL CODE AND BUILD DATE CODE ON PLATE
Design codeFIRST DESIGN
Diagnostic pressure portsNO DIAGNOSTIC PRESSURE PORT
Displacement73,7 CM3/R [4.50 IN3/R]
Drain port size location.750-16 UNF-2B SAE O-RING PORT - BOTTOM (TOP PLUGGED)
Flow comp unload valve19-21 BAR [276-305 LBF/IN2]
Front mounting input shaft4 BOLT C (SAE J744-127-4) WITH 38.1 [1.50] DIA STRAIGHT KEYED SHAFT (KEY INCLUDED), 62.0 [2.44] SHAFT EXTENSION
Input shaft rotationRIGHT-HAND ROTATION (CW) RIGHT SIDE SUCTION PORT, LEFT SIDE PRESSURE PORT
Main ports size locationSIDE PORTS; SUCTION - 2.000 SAE 4-BOLT SPLIT FLANGE PORT STANDARD PRESSURE SERIES (CODE 61) WITH 1/2-13 UNC-2B THREADS; PRESSURE- 1.000 SAE 4-BOLT SPLIT FLANGE PORT STANDARD PRESSURE SERIES (CODE 61) WITH 3/8-16 UNC-2B THREADS
Maximum displacement optionSTANDARD DISPLACEMENT
PaintBLUE PRIMER
Pressure compensator setting246-254 BAR [3568-3684 LBF/IN2]
Shaft sealSINGLE, ONE-WAY SHAFT SEAL, FLUOROCARBON
Special featuresQ250 VALVE PLATE
Torque sensing other compNO TORQUE SENSING SETTING OR OTHER COMPENSATION
