B&R 5PPC1200.121E-10B
Panel PC 1200, 12.1", glass front. CPU and memory: Intel…
- MPN
- 5PPC1200.121E-10B
- Category
- Display variants
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the B&R 5PPC1200.121E-10B?
Panel PC 1200, 12.1", glass front. CPU and memory: Intel Atom E3940 1.6 GHz, quad core, 4 GB LPDDR4 RAM. Display and touch screen: 12.1", 1280 x 800 pixels (WXGA) widescreen, multi-touch (projected capacitive), control cabinet installation, landscape format, clear glass. Interfaces: 2x Ethernet 10/100/1000 Mbit/s, 2x USB 3.0.
Specifications
General information
| Certifications – CE | Yes |
| Certifications – UKCA | Yes |
| Certifications – CRA (Cyber Resilience Act) | In preparation |
| Certifications – UL | cULus E115267; Industrial control equipment |
| LEDs | Power, Disk |
| B&R ID code | 0xA6F1 |
| Cooling | Passive |
| Power button | Yes |
| Reset button | Yes |
| Type | All-in-one PC |
Controller
| Processor – Type | Intel Atom x5-E3940 |
| Processor – Clock frequency | 1600 MHz |
| Processor – Number of cores | 4 |
| Processor – Architecture | 14 nm |
| Processor – Thermal design power (TDP) | 9.5 W |
| Processor – L2 cache | 2 MB |
| Processor – Intel 64 architecture | Yes |
| Processor – Intel Hyper-Threading Technology | No |
| Processor – Intel vPro Technology | No |
| Processor – Intel Virtualization Technology (VT-x) | Yes |
| Processor – Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Processor – Enhanced Intel SpeedStep Technology | Yes |
| Real-time clock – Accuracy | At 25°C: Typ. 12 ppm (1 second) per day (note: At max. specified ambient temperature: Typ. 58 ppm (5 seconds) - worst case 220 ppm (19 seconds).) |
| Real-time clock – Retention time | Approx. 8 years |
| Real-time clock – Battery-backed | Yes |
| Memory – Type | LPDDR4 SDRAM |
| Memory – Memory size | 4 GB |
| Memory – Velocity | DDR4L-2133 |
| Memory – Memory interface width | Dual channel |
| Memory – Removable | No |
| Graphics – Controller | Intel HD Graphics |
| Graphics – Max. dynamic graphics frequency | 600 MHz |
| Graphics – Color depth | Max. 32-bit |
| Graphics – DirectX support | 12 |
| Graphics – OpenGL support | 4.3 |
| Bootloader | UEFI BIOS |
| Chipset | Apollo Lake |
| Trusted Platform Module | TPM 2.0 |
| Power management | ACPI 5.0 |
Display
| Viewing angles – Horizontal | Direction L / Direction R = Typ. 80° |
| Viewing angles – Vertical | Direction U = Typ. 80° / Direction D = Typ. 65° |
| Backlight – Type | LED |
| Backlight – Brightness (dimmable) | Typ. 40 to 400 cd/m² |
| Backlight – Half-brightness time | 50,000 h |
| Filter glass – Transmittance | ≥85% |
| Filter glass – Anti-glare coating | No |
| Touch screen – Type | Multi-touch |
| Touch screen – Technology | PCT (projected capacitive touch) |
| Type | TFT color |
| Diagonal | 12.1" |
| Colors | 16.7 million |
| Resolution | WXGA, 1280 x 800 px |
| Contrast | Typ. 800:1 |
Interfaces
| CFast slot – Quantity | 1 |
| CFast slot – Type | SATA III (SATA 6.0 Gbit/s) |
| USB – Quantity | 2 |
| USB – Type | USB 3.0 |
| USB – Variant | Type A |
| USB – Transfer rate | Low speed (1.5 Mbit/s), full speed (12 Mbit/s), high speed (480 Mbit/s) to SuperSpeed (5 Gbit/s) (note: The SuperSpeed transfer rate (5 Gbit/s) is only possible with USB 3.0.) |
| USB – Current-carrying capacity | Max. 1 A per connection |
| Ethernet – Quantity | 2 |
| Ethernet – Variant | RJ45, shielded |
| Ethernet – Transfer rate | 10/100/1000 Mbit/s |
Electrical properties
| Nominal voltage | 24 VDC, SELV/PELV (note: IEC 61010-2-201 requirements must be observed.) |
| Nominal current | Max. 2.2 A |
| Operating voltage | 24 VDC ±25% |
| Inrush current | Typ. 5 A, max. 100 A for < 50 μs |
| Power consumption | 52.8 W (note: Power consumption including all interfaces.) |
| Overvoltage category per EN 61131-2 | II |
| Galvanic isolation | No |
Operating conditions
| Pollution degree per EN 61131-2 | Pollution degree 2 |
| Degree of protection per EN 60529 | IP20 on back, Rev. D5 and later: IP65 on front, up to Rev. D0: IP55 on front (note: Not evaluated by UL.) |
Ambient conditions
| Temperature – Operation | -20 to 60°C (note: The temperature specifications correspond to a specification at 500 meters above sea level. The max. ambient temperature is typically derated 1°C per 1000 meters starting at 500 m above sea level.) |
| Temperature – Storage | -20 to 80°C |
| Temperature – Transport | -20 to 80°C |
| Elevation – Operation | Max. 3000 m (note: The temperature specifications correspond to a specification at 500 meters above sea level. The max. ambient temperature is typically derated 1°C per 1000 meters starting at 500 m above sea level.) |
| Relative humidity | See section "Temperature/Humidity diagrams". |
Mechanical properties
| Front – Design | Black |
| Dimensions – Width | 324 mm |
| Dimensions – Height | 221.5 mm |
| Dimensions – Depth | 43.2 mm |
| Weight | Approx. 2230 g |
Accessories
Optional accessories (8)
| 5ACCRHMI.0018-000 | Accessories — HMI C80/PPC1200 battery compartment - 1x battery holder C80/PPC1200 - 1x battery including circuit board |
| 5CFAST.256G-10 | CFast cards — CFast 256 GB MLC |
| 5CFAST.128G-10 | CFast cards — CFast 128 GB MLC |
| 5CFAST.064G-10 | CFast cards — CFast 64 GB MLC |
| 5CFAST.032G-10 | CFast cards — CFast 32 GB MLC |
| 6ACCRPP3.0001-000 | Other — This installation kit contains the following replacement parts: 9 retaining clips with torque limiting; 1x 2-pin cage clamp terminal block;… |
| 0TB6102.3100-00 | Terminal blocks — Accessory 2-pin cage clamp terminal block (3.81) |
| 0TB6102.3000-00 | Terminal blocks — 2-pin accessory screw clamp terminal block (3.81) |
Downloads & documentation
Official documents from B&R, downloaded directly from the manufacturer.
Data sheets & manuals
CAD & dimension drawings
Certificates (1)
5PPC1200.121E-10B: frequently asked questions
When can 5PPC1200.121E-10B be shipped?
5PPC1200.121E-10B is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 5PPC1200.121E-10B in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 5PPC1200.121E-10B and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 5PPC1200.121E-10B, subject to availability and destination.
