B&R 5D5601.01

Provit 5600 panel 12.1" SVGA color TFT display

MPN: 5D5601.01

€1,166.00excl. VAT & shipping

In stock — 1 available·Ships within 1 business day

Need a larger quantity or a formal quote?

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the B&R 5D5601.01?

Provit 5600 panel 12.1" SVGA color TFT display, 46 function keys and 26 system keys, female PS/2 keyboard connector, IP65 protection (front).

Specifications

General information

Certifications – CE	Yes
Certifications – UKCA	Yes
Certifications – UL	cULus E115267; Industrial control equipment

Accessories

Optional accessories (8)

5SWHMI.0000-00	Accessories — HMI Drivers & Utilities DVD
5A5602.02	Undefined — Legend Strips Template 12.1" For display units 5D5601.01, 5D5601.02 and 5D5601.03. For 1 device.
5A5601.01	Undefined — IPC5000 cable set for display, touch screen and panel FDD (for installation of the IPC5000 on 5D560x.xx panels)
5A5600.03	Undefined — Provit 5600 Panel FDD for panels 5D5600.01, 5D5600.02, 5D5600.03, 5D5601.01, 5D5601.02, 5D5601.03.
5A5004.11	Undefined — Remote display cable 1x70 degree length 10 m, for Provit 5000/5600, with angled connector.
5A5004.10	Undefined — Remote CD-ROM / Display cable length 10 m, for Provit 5000/5600.
5A5004.06	Undefined — Remote display cable 1x70 degree length 5 m, for Provit 5000/5600, with angled connector.
5A5004.05	Undefined — Remote CD-ROM / Display cable length 5 m, for Provit 5000/5600.

Downloads & documentation

Official documents from B&R, downloaded directly from the manufacturer.

Data sheets & manuals

Provit 5000 User's ManualPDF · 31 MB · 5.30 (05/17/2011) - EN

CAD & dimension drawings

5D5601.01: frequently asked questions

When can 5D5601.01 be shipped?

5D5601.01 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 5D5601.01 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 5D5601.01 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 5D5601.01, subject to availability and destination.
