B&R 5ACCIHDD.1024-000
1 TB hard disk, SATA, For APC4100
- MPN
- 5ACCIHDD.1024-000
- Category
- Mass storage devices
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the B&R 5ACCIHDD.1024-000?
1 TB hard disk - SATA - For APC4100
Specifications
General information
| Certifications – CE | Yes |
| Certifications – UKCA | Yes |
| Certifications – CRA (Cyber Resilience Act) | In preparation |
Hard disk
| Data transfer rate – Internal | Max. 149 MB/s |
| Data transfer rate – To/From host | Max. 600 MB/s (SATA III) |
| Positioning time – Nominal (read access) | 11 ms |
| Positioning time – Nominal (write access) | 13 ms |
| Capacity | 1 TB |
| Number of heads | 2 |
| Number of sectors | 1,953,525,168 |
| Bytes per sector | 512 (logical) / 4096 (physical) |
| Cache | 128 MB |
| Speed | 5400 rpm ±0.2% |
| Startup time | Typ. 2.8 s (from 0 rpm to read access) |
| Service life | 2 years |
| MTBF | 800,000 h (note: At 8760 power-on hours (POH) and max. 55 TB per year (surface temperature 25°C).) |
| Interface | SATA III |
| Access time | Typ. 5.5 ms |
| Supported transfer modes | Up to SATA III |
Endurance
| S.M.A.R.T. support | Yes |
| Storage health data support | No |
Electrical properties
| Power consumption | Max. 2 W (max. 5 W during spin-up) |
Ambient conditions
| Temperature – Operation | 0 to 60°C (note: Temperature specifications at 305 meters above sea level. The temperature specification must be reduced linearly by 1°C every 305 meters. Temperature gradient: Max. 20°C per hour.) |
| Temperature – 24-hour operation | 0 to 60°C (note: Temperature specifications at 305 meters above sea level. The temperature specification must be reduced linearly by 1°C every 305 meters. Temperature gradient: Max. 20°C per hour.) |
| Temperature – Storage | -40 to 65°C (note: Temperature specifications at 305 meters above sea level. The temperature specification must be reduced linearly by 1°C every 305 meters. Temperature gradient: Max. 20°C per hour.) |
| Temperature – Transport | -40 to 65°C (note: Temperature specifications at 305 meters above sea level. The temperature specification must be reduced linearly by 1°C every 305 meters. Temperature gradient: Max. 20°C per hour.) |
| Relative humidity – Operation | 8 to 90%, non-condensing (note: Humidity gradient: Max. 20% per hour.) |
| Relative humidity – Storage | 5 to 95%, non-condensing (note: Humidity gradient: Max. 20% per hour.) |
| Relative humidity – Transport | 5 to 95%, non-condensing (note: Humidity gradient: Max. 20% per hour.) |
| Vibration – Operation | Not permitted (0 Hz, 0 g) |
| Shock – Operation | Not permitted (0 g, 0 ms) |
| Elevation – Operation | -305 to 3,048 m |
| Elevation – Storage | -305 to 12,192 m |
Mechanical properties
| Dimensions – Width | Approx. 7 mm |
| Dimensions – Height | Approx. 70 mm |
| Dimensions – Depth | Approx. 100 mm |
| Weight | Approx. 95 g |
Accessories
Required accessories (order separately)
| 5APC4100.MMCA-001 | Mass storage devices — APC4100 SSD/HDD cable set - for slot 2 |
| 5APC4100.MMCA-000 | Mass storage devices — APC4100 SSD/HDD cable set - for slot 1 |
| 5APC4100.ISSD-000 | Mass storage devices — APC4100 mass storage installation frame |
Optional accessories (3)
| 5MMHDD.1024-00 | Drives — 1 TB hard disk - SATA |
| 5ACCRPC4.MMFR-000 | Mass storage devices — HMI APC4100 SSD/HDD installation frame |
| 5ACCRPC4.CBLS-000 | Mass storage devices — HMI APC4100 cable set SSD/HDD |
Downloads & documentation
Official documents from B&R, downloaded directly from the manufacturer.
Data sheets & manuals
5ACCIHDD.1024-000: frequently asked questions
When can 5ACCIHDD.1024-000 be shipped?
5ACCIHDD.1024-000 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 5ACCIHDD.1024-000 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 5ACCIHDD.1024-000 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 5ACCIHDD.1024-000, subject to availability and destination.
