B&R 3D0480.6

B&R System 2005 digital output module (DO480): 16 transistor outputs, 24 VDC, 2 A per output

MPN: 3D0480.6
Category: Digital I/O Modules

Price and lead time confirmed within 1 business day

Discontinued by B&R — we can still source the original 3D0480.6 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the B&R 3D0480.6?

B&R System 2005 digital output module (DO480): 16 transistor outputs, 24 VDC, 2 A per output, 2 electrically isolated output groups, 24 A total nominal current. Single-width System 2005 backplane format.

Specifications

Channels	16
Voltage	24 VDC
Current per output	2 A
Total nominal current	24 A
Output groups	2 (electrically isolated)
Type	Transistor digital output
Format	System 2005 single-width

3D0480.6: frequently asked questions

Can I still buy the 3D0480.6 now that it is discontinued?

Yes. B&R has discontinued the 3D0480.6, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can 3D0480.6 be shipped?

3D0480.6 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 3D0480.6 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 3D0480.6 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3D0480.6, subject to availability and destination.
