B&R 2PS740.9
2010 power supply module 100-240 VAC, 100 W
- MPN
- 2PS740.9
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the B&R 2PS740.9?
2010 power supply module 100-240 VAC, 100 W
Specifications
General Information
| Description | 2010 Power Supply Module, 100-240 VAC, 100 W |
| C-UL-US Listed | Yes |
| Base Plate Module | BP200, BP201, BP210 |
| Input Voltage – Minimum | 90 VAC |
| Input Voltage – Nominal | 100 ... 240 VAC |
| Input Voltage – Maximum | 270 VAC |
| Input Voltage Frequency | 47 to 63 Hz |
| Overvoltage – Peak Value | 750 V |
| Overvoltage – Half Value duration | 1.3 msec non-periodic |
| Output Power | see Diagram "Output Power" |
| Current Requirements | Max. 1.1 A |
| Thermal Overload Protection | Monitors housing temperature |
| Current Limitation | Monitors output power |
| Status Display | LEDs |
| READY Relay | N.O. |
| Switching Voltage | Nom. 24 VDC / 230 VAC |
| Max. Load on Contact | 2A |
| Transient Voltage | 2.5 kV |
| Protection | External |
| Dimensions (H, W, D) [mm] | 285, 40, 185 |
Downloads & documentation
Official documents from B&R, downloaded directly from the manufacturer.
Data sheets & manuals
2PS740.9: frequently asked questions
When can 2PS740.9 be shipped?
2PS740.9 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 2PS740.9 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 2PS740.9 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 2PS740.9, subject to availability and destination.
