Bosch Rexroth R911389445
SERVOMOTOR MAD100C-0250-SA-S2-DK0-35-A1
- MPN
- R911389445
- Category
- MAD Force-ventilated
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Bosch Rexroth R911389445?
The high power density predestines the MAD motor series for applications in machine tools and printing machines as well as in metal forming. Fine-resolution encoder systems in single-turn or multi-turn design as well as outstanding radial runout ensure maximum machining precision. In addition to options such as keyway and holding brake, these motors are also available with special bearings for high-speed applications or for applications with increased radial loads. The motor degree of protection IP65 includes the blower motor and thus enables use even in rough industrial environments. The service-friendly motor design even allows easy fan replacement while the motor is running – particularly interesting in the printing industry.
Specifications
Specifications
| Maximum torque [Nm] | 91.0 |
| Maximum speed [rpm] | 9000.0 |
| Rated speed [min⁻¹] | 2500 |
| Flange size [mm] | 192 |
| Rated power [kW] | 10.47 |
| Cooling type | Axial fan, blowing |
| Motor type | without holding brake |
| Rated torque [Nm] | 40.0 |
| Maximum current [A] | 64.3 |
| Shaft length [mm] | 60 |
| Shaft diameter [mm] | 32 |
| Spigot [mm] | 130 |
| Bolt circle [mm] | 215 |
| Mounting hole (shaft) | 14 mm |
| Rotor inertia (without brake) value [kg/m²] | 0.0284 |
| Encoder design | Optical encoder, single-turn EnDat2.1, with 2048 increments |
| electrical connection | Terminal box, rotatable - right |
| Weight [kg] | 59 |
