SERVOMOTOR MAD130C-0200-SA-M2-BP0-35-N1

Name: Bosch Rexroth R911316226 – SERVOMOTOR MAD130C-0200-SA-M2-BP0-35-N1
Brand: Bosch Rexroth
SKU: R911316226

MPN: R911316226 · Brand: Bosch Rexroth

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	MAD Force-ventilated
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can R911316226 be shipped?

R911316226 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up R911316226 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for R911316226 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for R911316226, subject to availability and destination.

The high power density predestines the MAD motor series for applications in machine tools and printing machines as well as in metal forming. Fine-resolution encoder systems in single-turn or multi-turn design as well as outstanding radial runout ensure maximum machining precision. In addition to options such as keyway and holding brake, these motors are also available with special bearings for high-speed applications or for applications with increased radial loads. The motor degree of protection IP65 includes the blower motor and thus enables use even in rough industrial environments. The service-friendly motor design even allows easy fan replacement while the motor is running – particularly interesting in the printing industry.

Specifications

Maximum torque [Nm]	252.9
Maximum speed [rpm]	7500.0
Rated speed [min⁻¹]	2000
Flange size [mm]	262
Rated power [kW]	23.0
Cooling type	Axial fan, blowing
Motor type	without holding brake
Rated torque [Nm]	110.0
Maximum current [A]	106.7
Shaft length [mm]	110
Shaft diameter [mm]	42
Spigot [mm]	250
Bolt circle [mm]	300
Rotor inertia (without brake) value [kg/m²]	0.108
Encoder design	Multiturn absolute encoder, EnDat2.1, 2048 increments
electrical connection	Connector B-side
Weight [kg]	124
