DIRECTIONAL SPOOL VALVE 4WE6E6X/EG24K4QSAG24W

Name: Bosch Rexroth R901408820 – DIRECTIONAL SPOOL VALVE 4WE6E6X/EG24K4QSAG24W
Brand: Bosch Rexroth
SKU: R901408820

MPN: R901408820 · Brand: Bosch Rexroth

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Directional on/off valve
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can R901408820 be shipped?

R901408820 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up R901408820 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for R901408820 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for R901408820, subject to availability and destination.

Industrial hydraulic valve in a high performance range. Reliable switching of the oil flow direction according to hydraulic symbol.

Spool valve

Direct actuated

Specifications

Connection diagram	ISO 4401-03-02-0-05
Product family	WE6../E
Operating pressure, max. [bar]	350.0
Max. flow [l/min]	80.0
Spool symbol	Symbol E
Size	6
Type of actuation	with solenoid actuation
Number of ports	4
Number of switching positions	3
Supply voltage	24 VDC
Electrical connector	Connector, 3-pole (2 + PE)
Electrical connection description	Connector 3-pole (2 + PE) according to EN 175301-803
Hydraulic fluid	HFC; HL; HLP; HLPD; HVLP; HVLPD
Seals	NBR
Weight [kg]	2.64
