Home / Bosch Rexroth / Directional on/off valve / Bosch Rexroth R901364982

Bosch Rexroth R901364982

DIRECTIONAL SPOOL VALVE 4WEH10Y4X/6EW110N9ETK4/B10

MPN: R901364982
Category: Directional on/off valve

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Bosch Rexroth parts? We buy surplus →

What is the Bosch Rexroth R901364982?

Industrial hydraulic valve in a high performance range. Reliable switching of the oil flow direction according to hydraulic symbol.

Spool valve

Pilot-operated

Internal pilot oil supply, internal pilot oil return

Specifications

Connection diagram	ISO 4401-05-05-0-05
Product family	H-4W.H..
Operating pressure, max. [bar]	280.0
Max. flow [l/min]	160.0
Spool symbol	Symbol Y
Type of connection	Subplate mounting
Size	10
Type of actuation	with solenoid actuation
Number of ports	4
Number of switching positions	2
Supply voltage	110…120 VAC
Electrical connector	Connector, 3-pole (2 + PE)
Electrical connection description	Connector 3-pole (2 + PE) according to EN 175301-803
Conformity description	CE – Low-Voltage Directive 2014/35/EU; UKCA – Low-Voltage Directive SI2016/1091
Conformity	CE; UKCA
Hydraulic fluid	HFC; HL; HLP; HLPD; HVLP; HVLPD
Seals	NBR
Weight [kg]	7.51

R901364982: frequently asked questions

When can R901364982 be shipped?

R901364982 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up R901364982 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for R901364982 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for R901364982, subject to availability and destination.
