VANE PUMP PVQ1-1X/040RJ15UMB

Name: Bosch Rexroth R901076886 – VANE PUMP PVQ1-1X/040RJ15UMB
Brand: Bosch Rexroth
SKU: R901076886

MPN: R901076886 · Brand: Bosch Rexroth

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Rotary vane fixed displacement pumps
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can R901076886 be shipped?

R901076886 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up R901076886 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for R901076886 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for R901076886, subject to availability and destination.

Double-stroke vane pump, internally force compensated without hydraulic bearing load allows for a long life cycle. High efficiency in mobile applications thanks to axial gap compensation.

Rotary vane fixed displacement pump

For mobile and industrial applications in the open circuit

With NBR seals

Specifications

Displacement type	constant
Size [cm³]	40
Product family	PVQ
Operating pressure, max. [bar]	160.0
Max. flow [l/min]	59.0
Through-drive	without
Direction of rotation	clockwise rotation
Shaft end	Geared 22-4, 13T 16/32 DP, ISO 3019-1
Mounting flange	2-hole mounting flange 101-2 according to ISO 3019-1
Hydraulic fluid	HFC; HLP
Seals	NBR
Weight [kg]	12.34
