Bosch Rexroth R890000224

PROPORTIONAL DIRECTIONAL VALVE 4WRA6W30-3X/VN9/24K4

MPN: R890000224
Category: Proportional directional valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Bosch Rexroth parts? We buy surplus →

What is the Bosch Rexroth R890000224?

Industrial hydraulic valve in a high performance range. Reliable control of the oil flow direction according to hydraulic symbol.

Spool valve

Direct actuated

With concealed auxiliary actuation

Specifications

Connection diagram	ISO 4401-03-02-0-05
Product family	4WRA
Operating pressure, max. [bar]	350.0
Max. flow [l/min]	42.0
Spool symbol	Symbol W
Type of connection	Subplate mounting
Nominal flow [l/min]	26.0
Size	6
Type of actuation	Electrical with external electronics
Number of ports	4
Number of switching positions	3
Supply voltage	24 VDC
Electrical connector	Connector, 3-pole (2 + PE)
Electrical connection description	Connector 3-pole (2 + PE) according to EN 175301-803
Connectivity	Analog, command value 4…20 mA; Analog, command value ±10 V
Conformity	CE; REACH; RoHS
Hydraulic fluid	HDFR; HEES; HEPG; HETG; HFDU; HL; HLP; HLPD; HVLP; HVLPD
Seals	FKM
Weight [kg]	2
