Bosch Rexroth 3842406960

IDENTIFICATION SYSTEM CS: ID15 AS-I READER

MPN: 3842406960
Category: Read/write head ID 15

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Bosch Rexroth parts? We buy surplus →

What is the Bosch Rexroth 3842406960?

Read/Write Head ID 15/SLK

For transferring workpiece data between MDT.../28-L and an AS-i bus master.

Specifications

Conformity	CE; FCC
Mass [m] [kg]	0.1
Protection class	IP67
Ambient temperature [T]	-20 … +60 °C
Operating voltage DC [V]	26,5 … 31,6
Transmission frequency	125
Storage temperature [T]	-25 … +80 °C
Status indicator 01	3 LEDs
Connection 01	AS-i, profile 7.4
Shock and impact resistance (EN 60068-2-29)	40 g/6 ms
Shock and impact resistance (EN 60068-2-27)	50 g/11 ms
Write/read distance, static [mm]	20
Write/read distance, dynamic [mm]	15
Min. distance between 2 SLK (read, write) [mm]	400
Min. distance between 2 SLK (read) [mm]	200
Dynamic data transfer	Yes
Humidity	95%
Scope of delivery	Read/write head
Notice	EN 300330; EN 61326; Operating voltage via power pack; Vibration resistance according to DIN EN 60068-2-6; max. write/read distance dynamic at v = 20 m/min
Material information	Housing: PA
Max. current consumption [A]	0.1
Required accessories	Fastening kit according to the application
Weight [kg]	0.1
