Beckhoff ZK7266-3114-Axxx
B17, ENP cable, two cable solution, PUR, 5 G 1.5 mm² + (1 x 4 x AWG26), fixed installation, key 1 (2 x 24 V DC + PE)
- MPN
- ZK7266-3114-Axxx
- Category
- Hybrid cables
Price and lead time confirmed within 1 business day
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
What is the Beckhoff ZK7266-3114-Axxx?
EtherCAT/Ethernet cable, ENP, PUR, fixed installation, B17, plug, straight, female+male, pins 5+4, EtherCAT-coded – M8, plug, straight, male, 4-pin, A-coded – 7/8"-16 UN, socket, straight, female , 5-pin
Specifications
Specifications
| Installation size | 7/8"-16 UN |
| Connector type | socket |
| Contact type | female |
| Number of positions (face) | 5-pin |
| Coding | A‑coded |
| Mating cycles | ≥ 100 (according to IEC 60512-9a) |
| Wire termination | crimp connection |
| Shielding | no |
| Rated current | 12 A at 40°C (according to IEC 60512-3), 10 A (according to UL2238) |
| Rated voltage | 300 V (according to IEC 60664-1) |
| Recommended torque, nut | 0.4 Nm |
| Cross-section | 5 G 1.5 mm² (approx. AWG16) |
| Use | fixed installation |
| Material jacket | PUR (polyurethane) |
| Outer cable diameter | 3.65 mm ± 0.15 mm (0.1496" ± 0.0059") |
| Min. bending radius, moved | 15 x outer cable diameter |
| Max. number of cycles | 20 million (5 million with 14 x D, v = 5 m/s and a = 15 m/s², min. 1 million with 9.5 x D, a = 1 m/s², travel distance = 1 m) |
| Jacket color | green |
| Cross-section (Ethernet) | 1 x 4 x 0.14 mm² (AWG26) |
| Min. bending radius, fixed installation | 8 x outer cable diameter, 2.5 x outher cable diameter (fixed with single bend) |
| CE | yes |
| A1 | 73.60 mm |
| A2 | 23.00 mm |
| B1 | 41.00 mm |
| B2 | Ø 10.1 mm |
| D1 | 53.90 mm |
No matching specifications
ZK7266-3114-Axxx: frequently asked questions
When can ZK7266-3114-Axxx be shipped?
ZK7266-3114-Axxx is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up ZK7266-3114-Axxx in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for ZK7266-3114-Axxx and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for ZK7266-3114-Axxx, subject to availability and destination.
