Beckhoff – IE2320 Extension Box, 4-channel digital input + 4-channel digital output, 24 V DC, 3 ms, 2 A, Ø8

Name: Beckhoff – IE2320 Extension Box, 4-channel digital input + 4-channel digital output, 24 V DC, 3 ms, 2 A, Ø8
Brand: Beckhoff
SKU: IE2320

MPN: IE2320 · Brand: Beckhoff

Price on request

Discontinued by Beckhoff — we can still source the original IE2320 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	I/O service products (discontinued)
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

Can I still buy the IE2320 now that it is discontinued?

Yes. Beckhoff has discontinued the IE2320, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can IE2320 be shipped?

IE2320 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up IE2320 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for IE2320 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for IE2320, subject to availability and destination.

The IE2320 digital I/O module combines four digital inputs and four digital outputs in one device. The outputs handle load currents of up to 2 A, are short-circuit proof and protected against inverse polarity. The sum current for all four outputs is

Beckhoff IE2320 — Extension Box, 4-channel digital input + 4-channel digital output, 24 V DC, 3 ms, 2 A, Ø8. Beckhoff service-phase product: no longer in the current range. PartnerPLC sources discontinued and surplus Beckhoff automation parts — request a quote for price, condition and lead time.

Specifications

Technical data

Lifecycle	Service phase (discontinued, no longer in Beckhoff's product range)
Number of channels	4 inputs + 4 outputs
Input/output connections	8 mm, snap type
Input filter	3 ms
Signal voltage “0”	-3…+5 V
Signal voltage “1”	11…30 V, 6 mA input current (EN 61131-2, type 2)
Sensor supply	from control voltage, max. 0.5 A, short-circuit proof in total
Load type	resistive, inductive, lamp load
Rated load voltage	24 V DC (-15%/+20%)
Max. output current	2 A per channel, individually short-circuit proof, ∑ 4 A
Short-circuit current	typ. 4 A
Auxiliary power current	typ. 30 mA per channel
Current consumption from U S (without sensor current)	25 mA
Power supply connection	feed: 1 x M8 male socket, 4-pin, a-coded; downstream connection: 1 x M8 female socket, 4-pin, A-coded
Bit width in the process image	4 inputs + 4 outputs
Electrical isolation	channels/control voltage: no, between the channels: no, control voltage/fieldbus: yes, via IP-Link
Operating temperature	0…55°C
Storage temperature	-25…+85°C
Vibration/shock resistance	conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission	conforms to EN 61000-6-2/EN 61000-6-4
Protect. rating/installation pos.	IP65/66/67 (conforms to EN 60529)/variable
Approvals/markings	CE, UL
