Beckhoff ER2624-0002
EtherCAT Box, 4-channel relay output, 25 V AC, 30 V DC, 0.5 A AC, 2 A DC, M12, zinc die-cast
- MPN
- ER2624-0002
- Category
- ER2xxx | Digital output
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Beckhoff ER2624-0002?
The ER2624-0002 EtherCAT Box has four relays each of which has a single contact. The relay contact is suitable for use at up to 25 V AC or 30 V DC. The EtherCAT Box indicates its signal state by means of light emitting diodes. The ER2624-0002 has
Specifications
Specifications
| Protocol | EtherCAT |
| Bus interface | 2 x M8 socket, 4-pin, a-coded, shielded |
| Number of outputs | 4 x make contacts |
| Output connections | M12 x 1, 5-pin, a-coded |
| Rated load voltage | 25 V AC/30 V DC |
| Ohmic switching current | 0.5 A AC/2 A DC |
| Minimum permitted load | 10 µA at 10 mV DC |
| Load type | ohmic, inductive, lamp load |
| Nominal output voltage | 24 V DC (-15%/+20%) |
| Distributed clocks | – |
| Current consumption from US | 120 mA |
| Current consumption from US (without sensor current) | 120 mA |
| Power supply connection | feed: 1 x M8 male socket, 4-pin, a-coded; downstream connection: 1 x M8 female socket, 4-pin, a-coded |
| Operating cycles mech. (min.) | 1 x 108 |
| Operating cycles electr. (min.) | 2 x 105 (1 A/30 V DC) |
| Electrical isolation | 500 V |
| Special features | potential-free switching |
| Weight | approx. 265 g |
| Operating temperature | -25…+60°C |
| Storage temperature | -40…+85°C |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP65/66/67 (conforms to EN 60529)/variable |
| Approvals/markings | CE, UL |
| Dimensions (W x H x D) | 30 mm x 126 mm x 26.5 mm |
| Material | zinc die-cast |
| Installation | 2 fixing holes 3.5 mm diameter for M3 |
ER2624-0002: frequently asked questions
When can ER2624-0002 be shipped?
ER2624-0002 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up ER2624-0002 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for ER2624-0002 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for ER2624-0002, subject to availability and destination.
