Overcurrent protection terminal, 24 V DC, 2-channel, 6 A/4 A, extended functionalities
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | EL9xxx | System |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can EL9227-9664 be shipped?
EL9227-9664 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up EL9227-9664 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for EL9227-9664 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for EL9227-9664, subject to availability and destination.
The EL9227-9482 electronic overcurrent protection terminal is a 24 V DC EtherCAT Terminal with an electronic protection function. The EL9227-9482 is a 2-channel device and switches 24 V DC overcurrents off reliably. The rated current is fixed to 6 A/4 A.
Specifications
Specifications
| Technology | overcurrent protection terminal 24 V DC, 2-channel |
| Input current | max. 10 A |
| Rated current | 6 A/4 A |
| Number of inputs | 2 |
| Number of outputs | 2 |
| Hold after output switch-off | ≥ 10 s (temperature-dependent) |
| Advance warning output load | adjustable; 50…100% |
| Integrated fail-safe element | 10 A (F) | 6 A (T) |
| Over voltage power-off | ≥ 32 V DC |
| Advance warning low-voltage | adjustable; 17…24 V DC |
| Reverse polarity switch-off | yes |
| Backward switch-off | adjustable; 3-stage |
| Current consumption E-bus | typ. 80 mA |
| Nominal voltage | 24 V DC |
| Electrical isolation | 500 V (E-bus/signal voltage) |
| Special features | output 1 additionally via power contact, LED button, extended functionalities |
| Weight | approx. 55 g |
| Operating temperature | -25…+55°C |
| Storage temperature | -40…+85°C |
| Approvals/markings | CE, UL |
| Design form | compact terminal housing with signal LEDs |
| Material | polycarbonate |
| Installation | on 35 mm DIN rail, conforming to EN 60715 with lock |
| Side by side mounting by means of | double slot and key connection |
| Marking | labeling of the BZxxxx series |
| Wiring | solid conductor (s), flexible conductor (st) and ferrule (f): spring actuation by screwdriver |
| Connection cross-section | s*: 0.08…2.5 mm², st*: 0.08…2.5 mm², f*: 0.14…1.5 mm² |
| Connection cross-section AWG | s*: AWG28…14, st*: AWG28…14, f*: AWG26…16 |
| Stripping length | 8…9 mm |
| Current load power contacts | Imax: 10 A |
| Dimensions (W x H x D) | 12 mm x 100 mm x 68 mm |
