RJ45, plug, straight, male, 8-pin – M9, plug, straight, female
| Shielding | yes |
| Installation size | M9 |
| Connector type | plug |
| Contact type | female |
| Number of positions (face) | 8-pin |
| Rated current | 3 A at 40°C (according to IEC 61076-2-104) |
| Rated voltage | 125 V |
| Mating cycles | ≥ 500 |
| Cross-section (Ethernet) | 0.14 mm² (AWG26) |
| Use | fixed installation |
| Material jacket | PUR (polyurethane) |
| Outer cable diameter | 5.9 mm ± 0.2 mm (0.2323" ± 0.0079") |
| Min. bending radius, moved | 10 x outer cable diameter |
| Min. bending radius, fixed installation | 5 x outer cable diameter |
| Jacket color | green |
| A1 | 37.00 mm |
| B1 | 44.0 mm |
| B2 | Ø 14,0 mm |
No matching specifications
C9900-K639,-K641...K647 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Yes — mention it when you request a quote for C9900-K639,-K641...K647 and we'll include express shipping options in our reply.
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for C9900-K639,-K641...K647, subject to availability and destination.
