Balluff – BOS0191 BOS Q08M-NS-LE20-00,2-S49 – Through-beam sensors

Name: Balluff – BOS0191 BOS Q08M-NS-LE20-00,2-S49 – Through-beam sensors
Brand: Balluff
SKU: BOS0191

MPN: BOS0191 · Brand: Balluff

Price on request

Discontinued by Balluff — we can still source the original BOS0191 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Through-beam sensors
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)
Recommended replacement	BOS026E
Datasheet	Manufacturer datasheet ↗

Shipping & availability

Can I still buy the BOS0191 now that it is discontinued?

Yes. Balluff has discontinued the BOS0191, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Balluff names the BOS026E as its successor — we can quote both.

When can BOS0191 be shipped?

BOS0191 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up BOS0191 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for BOS0191 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for BOS0191, subject to availability and destination.

Balluff BOS0191 (BOS Q08M-NS-LE20-00,2-S49) — Through-beam sensor. Series: Q08M; Dimension: 8 x 44 x 8 mm; Interface: NPN normally open (NO); Principle of optical operation: Through-beam sensor (receiver); Light type: Laser red light. Discontinued by Balluff; Balluff names BOS026E as alternative. PartnerPLC supplies new, surplus and discontinued Balluff parts — request a quote for price, condition and lead time.

Specifications

Product

Lifecycle	Discontinued by Balluff
Type designation	BOS Q08M-NS-LE20-00,2-S49
Product group	Through-beam sensors
Balluff alternatives	BOS026E

Key features

Series	Q08M
Dimension	8 x 44 x 8 mm
Interface	NPN normally open (NO)
Principle of operation	Photoelectric sensor
Principle of optical operation	Through-beam sensor (receiver)
Light type	Laser red light
Range	0...3 m
Connection	Cable with connector, M8x1-Male, 3-pin, 0.20 m, PUR
Housing material	Zinc, Die casting, nickel-plated
Material sensing surface	PMMA
Operating voltage Ub	10...30 VDC
Approval/Conformity	CE cULus EAC WEEE
