Balluff – BOS0107 BOS 2K-PS-RH11-00,2-S75 – Diffuse sensor with background suppression

MPN: BOS0107 · Brand: Balluff

Price on request

Discontinued by Balluff — we can still source the original BOS0107 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Diffuse sensor with background suppression
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)
Recommended replacement	BOS020N
Datasheet	Manufacturer datasheet ↗

Shipping & availability

Can I still buy the BOS0107 now that it is discontinued?

Yes. Balluff has discontinued the BOS0107, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Balluff names the BOS020N as its successor — we can quote both.

When can BOS0107 be shipped?

BOS0107 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up BOS0107 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for BOS0107 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for BOS0107, subject to availability and destination.

Balluff BOS0107 (BOS 2K-PS-RH11-00,2-S75) — Diffuse sensor with background suppression. Series: 2K; Dimension: 7.6 x 25.1 x 13.5 mm; Interface: PNP normally open (NO); Principle of optical operation: Diffuse sensor, triangulation; Special optical feature: Background suppression. Discontinued by Balluff; Balluff names BOS020N as alternative. PartnerPLC supplies new, surplus and discontinued Balluff parts — request a quote for price, condition and lead time.

Specifications

Product

Lifecycle	Discontinued by Balluff
Type designation	BOS 2K-PS-RH11-00,2-S75
Product group	Diffuse sensor with background suppression
Balluff alternatives	BOS020N

Key features

Series	2K
Dimension	7.6 x 25.1 x 13.5 mm
Interface	PNP normally open (NO)
Principle of operation	Photoelectric sensor
Principle of optical operation	Diffuse sensor, triangulation
Special optical feature	Background suppression
Beam characteristic	Focus, typical at 15 mm
Light type	LED, red light
Light spot size	Ø 1 mm at focal point
Range	1...30 mm
Connection	Cable with connector, M8x1-Male, 4-pin, 0.20 m, PVC
Housing material	ABS
Material sensing surface	PMMA
Operating voltage Ub	10...30 VDC
Approval/Conformity	CE
